All Satellites Frequency List Update

Latest Update by JE9PEL, 24 Jul 2014

http://www.ne.jp/asahi/hamradio/je9pel/satslist.doc
http://www.ne.jp/asahi/hamradio/je9pel/satslist.xls

                                                                                                                    Active(*)
                                                                                                                    Inactive(i)
                                                                                                                    Reentered(r)
                                                                                                                    Failure(f)
Satellite               Number   Uplink          Downlink         Beacon       Mode                  Callsign       Earth Escape(e)
-----------------       -----    -----------     -----------      -------      -----------------     ------------   ---------------
AO-1  (Oscar-1)         00214       .               .             144.983      CW                                       r
AO-2  (Oscar-2)         00305       .               .             144.983      CW                                       r
AO-3  (Oscar-3)         01293    145.975-146.025 144.325-375         .         SSB,CW                                 i
AO-4  (Oscar-4)         01902    432.145-155     144.300-310         .         SSB,CW                                   r
AO-5  (Oscar-5)         04321       .             29.450          144.050      CW                                     i
AO-6  (Phase-2A)        06236    145.900-146.000  29.450-550         .         SSB,CW                                 i
AO-7  (Phase-2B)        07530    145.850-950      29.400-500       29.502      A                                    *
AO-7  (Phase-2B)        07530    432.125-175     145.975-925      145.970      B,C                                  *
AO-7  (Phase-2B)        07530       .           2304.100          435.100      D(RTTY)                                i
AO-8  (Phase-2D)        10703    145.850-900      29.400-500       29.402      SSB,CW                                 i
AO-8  (Phase-2D)        10703    145.900-146.000 435.200-100      435.095      SSB,CW                                 i
UO-9  (UoSAT-1)         12888       .            145.825/435.025 2401.000      SSB,CW                                   r
AO-10 (Phase-3B)        14129    435.030-180     145.975-825      145.810      SSB,CW                                 i
UO-11 (UoSAT-2)         14781       .            145.826/435.025 2401.500      (V)FM,(S)PSK          UOSAT-2        *
MIR                     16609    145.985         145.985          145.985      Packet                R0MIR-1            r
FO-12 (JAS-1)           16909    145.900-146.000 435.900-800      435.795      SSB,CW                                 i
FO-12 (JAS-1)           16909    145.85/87/89/91 435.910             .         1200bps JAS           8J1JAS           i
RS-12 (Sputnik)         21089     21.210-250      29.410-450       29.408      SSB,CW                                 i
RS-13 (Sputnik)         21089     21.260-300     145.860-900      145.862      SSB,CW                                 i
AO-13 (Phase-3C)        19216    435.423-573     145.975-825      145.812      SSB,CW                                   r
UO-14 (UoSAT-3)         20437    145.975         435.070             .         FM                                     i
RS-15 (Sputnik)         23439    145.858-898      29.354-394       29.352      SSB,CW                               *
AO-16 (PACSAT)          20439    145.920         437.026             .         FM/USB                                 i
AO-16 (PACSAT)          20439    145.920         437.026         2401.143      1200bps JAS           PACSAT-11,-12    i
DO-17 (DOVE)            20440       .            145.825         2401.220      1200bps AFSK          DOVE-1           i
WO-18 (WEBERSAT)        20441       .            437.104/075         .         1200bps PSK                            i
LO-19 (LUSAT)           20442    145.840-900     437.125/150      437.125      CW carrier            LUSAT-11, -12  *
FO-20 (JAS-1b)          20480    145.900-146.000 435.900-800      435.795      SSB,CW                                 i
FO-20 (JAS-1b)          20480    145.85/87/89/91 435.910             .         1200bps JAS           8J1JBS           i
RS-21 (Sputnik)         27394       .               .             145.825      CW                                       r
RS-22 (Mozhayets)       27939       .               .             435.352      CW                                   *
UO-22 (UoSAT-5)         21575    145.900/975     435.120          435.120      9600bps FSK           UOSAT5-11,-12    i
KO-23 (KITSAT-A)        22077    145.900/850     435.175          435.175      9600bps FSK           HL01-11,  -12    i
KO-25 (KITSAT-B)        22828    145.980/870     436.500          436.500      9600bps FSK           HL02-11,  -12    i
IO-26 (ITAMSAT)         22826    145.875-950     435.822/867      435.791      1200bps JAS           ITMSAT-11,-12  *
AO-27 (EYESAT-A)        22825    145.850         436.795          436.795      1200bps AFSK,FM                        i
PO-28 (POSAT)           22829    145.925/975     435.075/275         .         9600bps FSK           POSAT1-11,-12    i
FO-29 (JAS-2)           24278    145.900-146.000 435.900-800      435.795      SSB,CW,(DigiTalker)                  *
FO-29 (JAS-2)           24278    145.85/87/89/91 435.910             .         1200bps JAS           8J1JCS           i
RS-30 (Yubileiniy-1)    32953       .               .             435.215/315  CW                                   *
TO-31 (TMSAT-1)         25396    145.925/975     436.925/900      436.925      9600bps FSK           TMSAT1-11,-12    i
GO-32 (TechSat)         25397    145.850/930     435.225          435.225/325  9600bps FSK           4XTECH-11,-12  *
SAFIR-S                 25399       .               .            2401.900      9600bps FSK           DP1AIS           i
SO-33 (SEDSAT-1)        25509       .            437.910          437.910      9600bps FSK           SEDSAT-1         i
PO-34 (PANSAT)          25520    436.500         436.500             .         Spectrum                               i
ISS                     25544    145.825         145.825          145.825      1200bps AFSK          RS0ISS         *
ISS                     25544    145.990         145.800          145.800      1200bps AFSK          RS0ISS-3         i
ISS                     25544    437.550         437.550          437.550      1200bps AFSK          RS0ISS-4, -11    i
ISS                     25544    145.200         145.800             .         Voice(Reg 1)          NA1SS            i
ISS                     25544    144.490         145.800             .         Voice(Reg 2,3)        NA1SS            i
SO-35 (SUNSAT-1)        25636    436.291         145.825          145.825      9600bps, FM           SUNSAT-3         i
UO-36 (UoSAT-12)        25693    145.960         437.400/025      437.400     38400bps FSK           UO121-11, -12    i
WO-39 (JAWSAT)          26061    145.860         437.070/175         .         9600bps FSK                            i
OO-38 (OPAL)            26063       .            437.100          437.100      9600bps FSK           KF6RFX           i
AO-37 (ASUSAT)          26065    145.960/980     435.700             .         9600bps FSK                            i
RS-39 (Chibis-M)        38051       .               .             435.215/315  CW                                   *
AO-40 (Phase-3D)        26609       .               .            2401.323      400bps  PSK                            i
RS-40 (MiR)             38736       .               .             435.365      CW                                   *
SO-41 (SaudiSat-1a)     26545       .            436.775          436.775      9600bps FSK           SASAT1-11,-12    i
SO-42 (SaudiSat-1b)     26549       .            436.075          436.075      9600bps FSK           SASAT2-11,-12    i
SO-43 (Starshine)       26929       .               .             145.820      9600bps FSK           STRSHN             r
NO-44 (PCsat1)          26931    145.827         145.827          145.827      1200bps AFSK          (A) W3ADO-1    *
NO-44 (PCsat1)          26931    435.250         145.827          145.827      9600bps FSK           (A) PCSAT-1    *
NO-44 (PCsat1)          26931       .            144.390          144.390      1200bps AFSK          (B) PCSAT-11     i
NO-44 (PCsat1)          26931       .            144.390          144.390      9600bps FSK           (B) PCSAT-12     i
NO-45 (Sapphire)        26932    145.945         437.100          437.100      1200bps AFSK          KE6QMD           i
MO-46 (TiungSat)        26548    145.850/925     437.325          437.325     38400bps FSK           MYSAT3-11,-12    i
BO-47 (IDEFIX)          27422       .            145.840          145.840      400bps  BPSK                           i
BO-48 (IDEFIX)          27422       .            435.270          435.270      400bps  BPSK                           i
AO-49 (Rubin-2)         27605    435.275         145.825          145.825      U/1200,D/9600 MSK                      i
SO-50 (SaudiSat-1c)     27607    145.850         436.795             .         FM_tone 67.0Hz                       *
DTUSAT                  27842       .               .             437.475      2400bps AFSK          OZ2DTU           i
AAUSAT                  27846       .            437.450          437.450      9600bps GMSK                           i
CANX-1                  27847       .            437.880             .         1200bps AFSK          VA3SFL           i
QUAKESAT                27845       .            436.682          436.682      9600bps FSK           KD7OVB           i
AO-51 (Echo)            28375    145.920         435.300          435.150      FM_tone 67.0Hz                         i
AO-51 (Echo)            28375    145.860/880    2401.200          435.150      9600bps FSK           PECHO-11,-12     i
AO-51 (Echo)            28375   1268.700         435.150          435.150      9600bps FSK           PACB-11, -12     i
VO-52 (Hamsat)          28650    435.220-280     145.930-870      145.936      SSB,Carrier           Indian           i
VO-52 (Hamsat)          28650    435.225-275     145.925-875      145.860      SSB,CW                Dutch            i
PCSat2                           145.825         435.275          437.975      9600bps FSK           PC2TLM             r
UWE-1                   28892       .            437.505          437.505      1200bps AFSK          DP0UWE           i
XO-53 (SSETI)           28894       .            437.250          437.250      9600bps FSK           SSETI1           i
AO-54 (SuitSat)         28933       .            145.990             .         FM
CO-55 (CUTE-I)          27844       .            437.470          436.8375     1200bps AFSK          JQ1YCY         *
CO-56 (CUTE1.7)         28941       .            437.505          437.382      1200bps AFSK          JQ1YPC             r
CO-56 (CUTE1.7)         28941   1268.500         437.505          437.382      9600bps GMSK                             r
CO-57 (XI-IV)           27848       .            437.490          436.8475     1200bps AFSK,CW       JQ1YCW         *
CO-58 (XI-V)            28895       .            437.345          437.465      1200bps AFSK,CW       JQ1YGW         *
NCUBE2                  28897       .               .             437.305      9600bps FSK           LA1CUB           i
AeroCube1                           .            902/928             .         9600bps GFSK                               f
HAUSAT-1                            .            437.465          437.465      1200bps AFSK          D90HP                f
ICEcube1                            .            437.305             .         9600bps FSK           W2CXM                f
ICEcube2                            .            437.425             .         9600bps FSK           N2VR                 f
ION                                 .            437.505          437.505      1200bps AFSK                               f
KUTESat Pathfinder                  .            437.385             .         1200bps AFSK          KC0RMW               f
Mea Huaka'i Voyager                 .            437.405/5.840GHz    .         1200bps AFSK                               f
MEROPE                              .            145.980             .         1200bps AFSK          K7MSU-1              f
nCUBE-1                             .            437.305             .         9600bps GMSK          LA1CUB               f
PICPOT                              .            437.485             .         9600bps FSK                                f
PICPOT                              .           2440.000             .         10kbit  GFSK                               f
PolySat CP1                         .            436.845             .         15bps DTMF,CW         N6CP                 f
PolySat CP2                         .            437.325          437.325      1200bps AFSK                               f
RINCON                              .            436.870          437.345      1200bps AFSK          WA4CEW               f
SACRED                              .            436.870             .         1200bps AFSK          WA4CEW               f
SEEDS                               .            437.485             .         1200bps AFSK          JQ1YGU               f
HO-59 (HITSAT)          29484    145.980         437.425          437.275      1200bps AFSK          JR8YJT             r
GeneSat-1               29655       .            437.065/100      437.065      1200bps AFSK          KE7EGC             r
NMARS                   29662    148.975          27.9652            .         1200bps FM/USB                           r
NO-60 (RAFT)            29661    145.825         145.825          145.825      1200bps AFSK          RAFT               r
NO-61 (ANDE)            29664    145.825         145.825          145.825      1200bps AFSK          ANDE-1             r
NO-62 (FCAL)            29667       .            437.385          437.385      1200bps AFSK          KD4HBO             r
PO-63 (PehuenSat)       29712       .            145.825          145.825      1200bps AFSK          LU1YUC           i
AeroCube-2              31122       .            902-928             .         9600bps GFSK                           i
MAST                    31126       .        2400-2483.5             .                 FHSS                           i
PolySat CP3             31128       .            436.845             .         1200bps AFSK                           i
LIBERTAD-1              31129       .            437.405          437.399      1200bps AFSK          5K3L             i
CAPE-1                  31130       .            435.245          435.248      1200bps AFSK          K5USL            i
PolySat CP4             31132       .            437.325          437.323      1200bps SSB           N6CP             i
CSTB-1                  31133       .            400.0375            .         1200bps AFSK                           i
CUTE1.7+APDII           32785   1267.600         437.475             .         9600bps GMSK          JQ1YTC         *
CO-65  (APDII)          32785       .            437.475          437.275      1200bps AFSK,CW       JQ1YTC         *
COMPASS-1               32787       .            437.405          437.275      1200bps AFSK,CW       DP0COM         *
AAUSAT-II               32788       .            437.432          437.432      1200bps FFSK/MSK                     *
AAUSAT-II               32788       .            437.432          437.432      9600bps FSK           OZ2CUB           i
DO-64 (DELFI-C3)        32789       .            145.870          145.867      1200bps BPSK          DLFIC3         *
DO-64 (DELFI-C3)        32789    435.570-530     145.880-920      145.930      SSB,CW                DLFIC3           i
CANX-2                  32790       .            437.478             .         GMSK                  VA3SFL         *
CANX-2                  32790       .           2200.000             .         32Kbps-256Kbps BPSK   VA3SFL         *
CO-66 (SEEDS-II)        32791       .            437.485          437.485      1k2AFSK,CW,DigiTalker JQ1YGU         *
RS-30 (Yubileiniy)      32953       .            435.315/215      435.315      CW                    RS30           *
PRISM (HITOMI)          33493       .            437.425          437.250      1k2AFSK,9k6GMSK,CW    JQ1YCX         *
KAGAYAKI                33495       .            437.375          437.375      9600bps FSK,CW                         i
SOHLA-1 (MAIDO-1)       33496       .            437.505          437.505      1200bps AFSK,CW       JL3YUS           i
STARS (KUKAI mother)    33498       .            437.485          437.305      1200bps FM,CW         JR5YBN         *
STARS (KUKAI daught)    33498       .            437.465          437.275      1200bps FM,CW         JR5YBO         *
KKS-1 (KISEKI)          33499       .            437.445          437.385      1200bps AFSK,CW       JQ1YYY         *
PharmaSat-1             35002       .            437.465          437.465      1200bps AFSK          KE7EGC           i
CP-6                    35003       .            437.365          437.365      1200bps AFSK,CW       N6CP             i
HawkSat-1               35004       .            437.345          437.345      1200bps AFSK                           i
DRAGONSat(AggieSat-2)   35690       .            436.250          436.250     19200bps FSK                              r
DRAGONSat(BEVO-1)       35690       .            437.325          437.325      9600bps FSK                              r
ANDE-2(Pollux)          35693       .            145.825          145.825      1200bps AFSK          POLLUX-1           r
ANDE-2(Castor)          35694       .            145.825          145.825      1200bps AFSK          KD4HBO-1           r
RS-28 (UgatuSat)        35868       .            435.266/442      435.264      CW                    RS28             i
RS-38 (Tatiana-2)       35869       .            435.448/498      435.490      CW                    RS38             i
SO-67 (SumbandilaSat)   35870    145.875         435.345          435.300      FM_tone 233.6Hz                      *
SwissCube-1             35932       .            437.505          437.505      1200bps BFSK,CW       HB9EG1         *
BeeSat                  35933       .            436.000          436.000      9600/4800bps GMSK     DP0BEE         *
UWE-2                   35934       .            437.385          437.385      1200bps AFSK,CW                        i
ITU-pSat1               35935       .            437.325          437.325     19200bps GFSK,CW                      *
HO-68 (XW-1)            36122    145.925-975     435.765-715      435.790      SSB inverting,CW      BJ1SA-11,-12     i
HO-68 (XW-1)            36122    145.825         435.675          435.790      FM_tone67Hz,CW_only   BJ1SA-11,-12   *
Waseda-SAT2             36574       .            437.485          437.485      1200bps PCMFSK,CW     WASEDA             r
Negai*"                 36575       .            437.305          437.305      1200bps AFSK,CW       JQ1ZEX             r
UNITEC-1                36578       .           5840.000         5840.000      1200bps AFSK,CW       JQ1ZUN                 e
StudSat                 36796    437.505         437.505          437.861      9600bps FSK,CW                         i
TIsat-1                 36799    145.980         437.305          437.305      FM,AFSK,PSK,CW        HB9DE          *
RAX-1                   37223       .            437.505          437.505      9600bps GMSK          RAX-1            i
O/OREOS                 37224       .            437.305          437.301      1200bps AFSK          KF6JBP         *
FO-69 (FASTRAC-1)       37227    145.825         437.345          437.342      1200bps AFSK          FAST1            i
FO-69 (FASTRAC-1)       37227    145.980         437.345          437.342      9600bps FSK           FAST1            i
NanoSail-D2             37361       .               .             437.270      1200bps AFSK          KE7EGC             r
FO-70 (FASTRAC-2)       37380    435.025         145.825          145.825      1200bps AFSK          FAST2            i
FO-70 (FASTRAC-2)       37380    437.345         145.825          145.825      9600bps FSK           FAST2            i
CAERUS                              .            437.600          437.600      1200bps AFSK          KJ6FIX-1
ARISSat-1               37772    435.742-758     145.938-922      145.919/939  FM, linear/inverting                     r
ARISSat-1               37772       .            145.950          145.950      FM, VOICE/SSTV/Telemetry                 r
ARISSat-1               37772       .            145.9182         145.919      BPSK-1000/CW          RS01S              r
ARISSat-1               37772       .            145.939          145.939      BPSK-400/CW                              r
Jugnu                   37839       .            437.505          437.2759     CW                                   *
SRMSAT                  37841    145.900         437.500          437.425      CW                                   *
RAX-2                   37853       .            437.345          437.345      9600bps GMSK                           i
AO-71 (AubieSat-1)      37854       .            437.475          437.473      1200bps AFSK,CW                      *
E1P-U2                  37855       .            437.505          437.502      1200bps AFSK,LSB                     *
M-Cubed                 37855       .            437.485          437.485      9600bps GMSK                         *
LARES                   38077       .               .                .                               (non-amateur)
ALMASat-1               38078       .            437.465/2407.850 437.465      1200bps FSK           ALMASAT          i
e-st@r                  38079       .            437.445          437.445      1200bps AFSK          E-STAR-I         i
Goliat                  38080       .            437.485          437.485      1200bps AFSK,CW       YO7MJF           i
MaSat-1 (MO-72)         38081       .            437.345          437.345      625/1250bps GFSK,CW   HA5MASAT       *
Xatcobeo                38082       .            437.365/145.940  437.365      1200bps FFSK,SSR,CW                  *
PW-Sat1                 38083    435.020         145.900          145.902      1200bps BPSK,FM,CW    VOID             i
Robusta                 38084       .            437.325          437.325      1200bps FM                             i
UNICubeSAT              38085       .            437.305          437.305      9600bps FSK                            i
Horyu-2                 38340       .            437.375          437.378/372  1200bps FSK/CW        JG6YBW         *
PROITERES               38756       .            437.485          437.485      1200bps AFSK,CW       JL3YZL           i
AENEAS                  38760       .            437.600          437.600      1200bps AFSK          KE6YFA-1       *
CSSWE                   38761       .            437.349          437.349      9600bps GMSK          CSSWE7           i
CXBN                    38762       .            437.525          437.525      9600bps GFSK                           i
CP5                     38763       .            437.405          437.405      1200bps AFSK LSB      CP5              i
RAIKO                   38852       .            2.285GHz,13GHz  2285.000      38.4Kbps-500Kbps BPSK (non-amateur)
FITSAT-1                38853       .            437.445, 5.84GHz 437.250      1200bps/115.2Kbps     JG6YEW             r
TechEdSat               38854       .            437.465          437.465      1200bps FM,CW         KJ6TVO             r
F-1                     38855       .            145.980          437.485      1200bps FM,AFSK,CW    XV1VN              r
WE_WISH                 38856       .            437.515          437.505      2400bps FM,SSTV,CW    JQ1ZIJ             r
AAUSat3                 39087       .            437.425          437.425      4800bps FSK,CW        OZ3CUB         *
STRaND-1                39090       .            437.568          437.568      9600bps GMSK                         *
TugSat-1 (CanX-3B)      39091       .            145.890/437.365/2234.400      32Kbps-256Kbps BPSK                    i
UniBRITE (CanX-3A)      39092       .            145.890          145.890      CW                                     i
Bion-M1                 39130       .               .                .                               (non-amateur)
OSSI-1                  39131       .            437.525          145.980      1200bps AFSK,CW
AIST-2 (RS-43)          39133       .            435.215          435.265      FM,CW                                *
SOMP                    39134       .            437.485          437.503      1200bps AFSK,CW       DP0TUD         *
BEESAT-3                39135       .            435.950          435.950      4800bps GMSK,CW       DP0BEF           i
BEESAT-2                39136       .            435.950          435.950      4800bps GMSK,CW       DP0BEF         *
GRAHAM   (PhoneSat1)    39142       .            437.425     2401.200-2431.200 1200bps AFSK          KJ6KRW-2           r
BELL     (PhoneSat1)    39143       .            437.425     2401.200-2431.200 1200bps AFSK          KJ6KRW-1           r
Dove-1,2                39144       .            145.825         2420.000      1200bps AFSK                             r
ALEXANDER(PhoneSat2)    39146       .            437.425     2401.200-2431.200 1200bps AFSK          KJ6KRW             r
NEE-01 Pegaso           39151       .            910.000(bandwidth 25MHz)      AMTV-CW, SSTV         (non-amateur)
TURKSAT-3USAT           39152    145.940-990     435.200-250      437.225      Transponder(V/U),CW                    i
CubeBug-1               39153       .            437.445          437.4383     1200bps AFSK          CUBEB1         *
EstCube-1               39161       .            437.505/2401.250 437.254      9600bps GMSK,CW       ES5E-11,ES5E/S *
CUSat-1                 39266       .            437.405          437.405      1200bps AFSK          BOTTOM         *
DANDE                   39267       .            436.750          436.750      9600bps GMSK          DANDE-2        *
CUSat-2                 39271       .            437.485          437.485      1200bps AFSK          WG2XTI           i
PhoneSat2.4             39381       .            437.425/2401.200-2431.200     1200bps AFSK          KJ6KRW         *
CAPE-2 (LO-75)          39382    145.825         145.822/437.325  145.825      1200bps AFSK,CW,Voice W5UL-15        *
DragonSat-1             39383       .            145.870             .         9600bps FSK                            i
KySat-2                 39384       .            437.405          437.402      9600bps FSK           KK4AJJ           i
TJ3Sat                  39385       .               .             437.320      CW                                     i
NPS-SCAT                39389       .            437.525/2401.200-2447.600     1200bps AFSK,CW       K6NPS            i
COPPER                  39395       .            437.290/2403.000-2403.400     9600bps FSK                            i
Black Knight-1          39398       .            437.345             .                                                i
Trailblazer-1           39400       .            437.425             .         9600bps FSK                            i
SwampSat                39402       .            437.385             .         9600bps FSK                            i
Ho'oponopono-2          39403       .            427.220             .         9600bps FSK/GMSK                       i
ChargerSat-1            39405       .            437.405             .         9600bps FSK                            i
Vermont Lunar           39407       .            437.305             .         9600bps FSK           W1VTC2         *
ArduSat-1               39412       .            437.325          437.000      9600bps MSK,CW        WG9XFC-1       *
PicoDragon              39413       .            437.xxx          437.250      1200bps AFSK,CW       XV9PID             r
ArduSat-X               39414       .            437.345          437.007      9600bps MSK,CW        WG9XFC-X       *
TechEdSat-3             39415       .            437.465          437.465      1200bps AFSK,CW                        i
ZACube-1                39417    145.860         437.345           14.099      1k2AFSK,9k6GMSK,CW    123456         *
OPTOS                   39420       .               .                .                               (non-amateur)
UniSat-5                39421       .            437.175/425         .         9600bps GMSK                           i
WNISAT-1                39423       .               .                .                               (non-amateur)
Triton-1                39427    435.xxx         145.822/860     2408.000      1200bps RC-BPSK       TRIV0,TRIV1      i
Delfi-n3Xt              39428       .            145.870/930     2405.000      2400bps BPSK,MSK                       i
Delfi-n3Xt              39428    435.530-570     145.880-920         .         Transponder(U/V)                       i
Dove-3                  39429       .               .                .                               (non-amateur)
GOMX-1                  39430       .            437.250             .         1k2/2k4/4k8/9k6 GMSK                 *
BRITE-PL                39431       .            437.365/2234.400 145.890      32Kbps-256Kbps                       *
ICUBE-1                 39432    435.060         145.947             .         1200bps BPSK/FM-DSB_Transponder        i
Humsat-D                39433       .            437.325/525      437.325      CW                                   *
Dove-4                  39434       .               .                .                               (non-amateur)
Wren                    39435       .            437.405          437.405      1200bps FSK,CW                         i
Eagle-2($50SAT,MO-76)   39436       .            437.505          437.505      9600bps GFSK,RTTY,CW                 *
EAGLE-1(BeakerSat-1)    39437       .            437.465             .         9600bps GFSK                           i
VELOX-P2                39438    437.305         145.980          145.980      1200bps BPSK,CW                        i
First-MOVE              39439    435.520         145.970          145.970      1200bps BPSK,CW       MOVE1            i
CubeBug-2 (LO-74)       39440       .            437.445             .         1k2 AFSK,9k6 FSK      CUBEB2-6       *
NEE-02 Krysaor          39441       .            980.000(bandwidth 25MHz)                            (non-amateur)
PUCP-SAT-1              39442    145.840         145.840/437.200     .         1200bps AFSK                           i
Qubescout-S1            39443       .            437.525             .         9600bps GMSK                           i
FUNcube-1 (AO-73)       39444    435.150-130     145.950-970         .         Inverting(U/V)                       *
FUNcube-1 (AO-73)       39444       .            145.935             .         1200bps BPSK                         *
HiNCube                 39445       .            437.305             .                                                i
UWE-3                   39446       .            435.000/436.395/437.385       9600bps FSK,CW        DP0UWG         *
FIREBIRD-U1,U2          39463,4     .            437.405/230         .        19200bps,9600bps GMSK  K7MSU          *
ALICE                   39467       .            460.xxx             .         GFSK                  (non-amateur)
MCubed-2                39469       .            437.485          437.479      9600bps GMSK          NOCALL           i
CUNYSAT-1               39470       .            437.505          437.505      9600bps GMSK,CW                        i
IPEX                    39471       .            437.270          437.270      9600bps GMSK,CW       KJ6KSL-1       *
AIST-1(RS-41)           39492       .               .             435.265      CW                                   *
E-Star-2                            .            437.485             .         1200bps AFSK                           i
Pocket-PUCP                         .            437.200          437.200      1200bps AFSK,CW                        i
TetherSat                           .            437.100/305         .         9600bps GFSK                           i
SkyCube                 39567       .            915.000             .         57.6Kbps              (non-amateur)
LitSat-1                39568    435.135-165     145.965-935         .         SSB                                      r
LitSat-1                39568    435.550         145.845          435.1375     9600bps FSK,CW        LY1LS              r
LituanicaSAT-1(LO-78)   39569    145.950         435.1755            .         FM_tone 67.0Hz                       *
LituanicaSAT-1(LO-78)   39569    145.850         437.543          437.275      9600bps FSK,CW        LY5N           *
ArduSat-2               39570       .            437.xxx             .         9600bps MSK CCSDS                      i
UAPSat-1                39571    145.980         437.385          437.385      1200bps AFSK          OA0UAP-1         i
Chasqui-1                           .            437.250             .
ShindaiSat              39572       .            437.305          437.485      1200bps AFSK,CW       JR0ZST         *
ITF-1                   39573       .               .             437.525      CW                    JQ1ZLO             r
OPUSAT                  39575       .            437.154          437.154      1k2AFSK,9k6GFSK,CW    JL3ZCA             r
TeikyoSat-3             39576       .            437.450          437.450      1200bps AFSK,CW       JQ1ZKM           i
ARTSAT1-INVADER(CO-77)  39577       .            437.200          437.325      1k2AFSK,DigiTalker,CW JQ1ZKK         *
KSAT2                   39578       .            S,Ku-band           .         200Kbps,1Mbps G1D     (non-amateur)
STARS-II (Mother)       39579       .            437.405          437.245      1200bps AFSK,CW       JR5YDX             r
STARS-II (Daughter)     39579       .            437.425          437.255      1200bps AFSK,CW       JR5YDY             r
SporeSat                39681       .            437.100/2401.200-2431.200     1200bps AFSK
TSAT(TestSat-Lite)      39682       .               .                .
All-Star/THEIA          39683       .           2401.700             .         256Kbps BPSK          COSGC1AS
PhoneSat2.5             39684       .            437.425/2401.200-2431.200     1200bps AFSK          KJ6KRW         *
KickSat                 39685       .            437.505/2401.000-2436.200     1200bps AFSK          KD2BHC             r
Sprites                             .            437.240             .         125bps  MSK
UNIFORM-1               39767       .               .                .                               (non-amateur)
SOCRATES                39768       .               .                .                               (non-amateur)
RISING-2                39769    435.xxx        2401.xxx             .         1200bps 9600-96000bps (non-amateur)
SPROUT                  39770       .            437.525          437.525      1k2AFSK,9k6GMSK,CW    JQ1ZJQ         *
SPROUT                  39770    437.600         437.600             .         Digipeater,Digitalker,SSTV           *
UniSat-6                40012       .            437.425             .         9600bps GMSK          IZ0VXZ         *
BugSat-1                40014       .            437.445             .         9600bps GMSK          LU7AA          *
SaudiSat-4              40016       .               .                .         Ka-band transponder
TabletSat-Aurora        40017       .            435.550/436.100/437.050       9600bps GMSK,D-STAR                  *
DUCHIFAT                40021       .            145.980          145.980      1200bps BPSK,CW       4X4HSL         *
PACE                    40023       .            437.485          437.485      1200bps AFSK,CW
NanosatC-Br1            40024    435.xxx         145.865          145.865      1200bps BPSK,CW       NCBR1          *
QB50p1/FUNCube-3(EO-79) 40025    435.035-435.065 145.935-145.965  145.815      1200bps BPSK,CW       QB50P1         *
POPSAT-HIP1             40028       .            437.405          437.405      1k2,9k6 CCSDS,CW      POPSAT         *
DTUSat-2                40030   1268.900        2401.835             .         9k6CPFSK/1k2,19k2,38k4MSK
QB50p2(EO-80)           40032       .            145.880/840      145.880      1k2BPSK,9k6FSK,CW     QB50P2         *
ANTELSat                40034       .            437.575/2403.000 437.280      1k2 AFSK,GFSK/MSK,CW  CX1SAT         *
Perseus-M2              40037       .            400.190             .         9600bps GFSK          (non-amateur)
Perseus-M1              40039       .            400.160             .         9600bps GFSK          (non-amateur)
PolyITAN                40042       .            437.675          437.675      9600bps 2FSK,CW       EM0UKP         *
TigriSat                40043       .            435.000             .         9600bps FSK           HNATIG         *
ESTELLE                             .            U,S-band,5.8GHz     .         1Mbps-10Mbps,GFSK,BPSK
UNSA-SAT1                           .            3.4GHz              .         230Kbps BPSK
AISat                   40054       .               .             437.250/511  CW                    DP0AIS         *
CanX-4                  40055       .            145.890/2234.400 437.365      32Kbps-256Kbps BPSK
CanX-5                  40056       .            145.890/2234.400 437.365      32Kbps-256Kbps BPSK
VELOX-I                 40057       .            145.980          145.980      9600bps FSK,CW        VELOXI         *
IiNUSat                          145.950         436.915             .         1k2,9k6 2FSK
DX-1                    40071    144.975-145.025 434.975-435.025  438.225      9600bps GFSK          DAURIA         *
UKube-1                 40074    435.020-435.040 145.960-145.940     .         Transponder
UKube-1                 40074       .           2401.000          145.840      1200bps BPSK,CW       UKUBE1         *
FUNcube-2               40074    435.060-435.080 145.950-145.930     .         Transponder
FUNcube-2               40074       .               .             145.915      1200bps BPSK                         *
myPocketQub                         .            437.425-437.525     .
Venta-1                             .            437.325             .
Argus                               .            437.290/2403.000-2403.400     1200bps AFSK
EDSN                                .            437.100/2401.200-2431.200     1200bps AFSK
HawaiiSat-1(HiakaSat-1)             .            V,U,S-Band          .         9600bps GFSK
ORS-Squared                         .            437.325             .         9600bps GMSK
PrintSat                            .            437.325             .         9600bps GMSK


RS series

Satellite             Number   Launch          Downlink             Active(*),Inactive(i),Reentered(r)
---------------       -----    ---------       --------------       ----------------------------------
RS-1  (Radio 1)       11085    26Oct1978                            Non-Operational    i
RS-2  (Radio 2)       11086    26Oct1978                            Non-Operational    i
RS-3  (Radio 3)       12997    17Dec1981                            Non-Operational    i
RS-4  (Radio 4)       13000    17Dec1981                            Non-Operational    i
RS-5  (Radio 5)       12999    17Dec1981                            Non-Operational    i
RS-6  (Radio 6)       13002    17Dec1981                            Non-Operational    i
RS-7  (Radio 7)       13001    17Dec1981                            Non-Operational    i
RS-8  (Radio 8)       12998    17Dec1981                            Non-Operational    i
RS-10 (COSMOS 1861)   18129    23Jun1987        29.357/403          Non-Operational    i
RS-11 (COSMOS 1861)   18129    23Jun1987        29.357/403          Non-Operational    i
RS-12 (COSMOS 2123)   21089    05Feb1991        29.408/454          Non-Operational    i
RS-13 (COSMOS 2123)   21089    05Feb1991        21.138/29.504       Non-Operational    i
RS-14 (Informator-1)  21087    29Jan1991       145.822/948          Non-Operational    i
RS-15 (Radio Rosto)   23439    26Dec1994        29.3525/3987        Operational      *
RS-16 (Mozhayets-2)   24744    04Mar1997       435.510              Non-Operational      r
RS-17 (Sputnik 40)    24958    05Oct1997       145.820              Non-Operational      r
RS-18 (Sputnik 41)    25533    25Oct1998       145.812              Non-Operational      r
RS-19 (Sputnik 99)    25685    16Apr1998       145.815              Non-Operational      r
RS-20 (Mozhayets-3)   27560    28Nov2002       145.828/435.319      Unknown            i
RS-21 (Kolibri-2000)  27394    26Nov2001       145.825              Unknown            i
RS-22 (Mozhayets-4)   27939    27Sep2003       435.352              Operational      *
RS-23 (Tatyana)                20Jan2005       435.215/315          Non-Operational
RS-25 (Mozhayets-5)   28898    27Oct2005       435.325              Unknown            i
RS-26 (Sinah-1)       28893    05Oct2005                            Engineering        i
RS-27 (Baumanets-1)            26Jul2006                            Launch failed
RS-28 (UgatuSat)      35868    17Sep2009       435.264              Unknown            i
RS-30 (Yubileiniy-1) 32953     23May2008       435.215/315          Operational      *
RS-38 (Tatyana-2)     35869    17Sep2009       435.490              Non-Operational    i
RS-39 (Chibis-M)      38051    25Jan2012       435.215/315          Operational      *
RS-40 (MiR)           38736    28Jul2012       435.365              Operational      *
RS-41 (AIST-1)        39492    28Dec2013       435.265              Operational      *
RS-43 (AIST-2)        39133    19Apr2013       435.215/265          Operational      *


RS Satellites update written by RW3DZ and edited by DK3WN/JE9PEL on 9 Jan 2010.

RS-28 (UGATUSAT,Ufa)  failed due to malfunction of electronics
RS-29 (STERKH)        ID was reserved for this satellite but they used their own TRX rig and this number was omitted so far
RS-30 (Yubileyny-1)   operational
RS-31 to RS-37        were used for ORBCOMM satellites under contract from OHB-systems
RS-38 (Tatyana-2)     is working perfect and operate well under Kaluga control
RS-39 (Chibis)        is under construction since 2006 and may be on orbit in 2011
RS-40 (Yubileyny-2)   will be on orbit in 2010
RS-   (      )        next new RS satellites also in progress


[Reference]

http://ww2.amsat.org/?page_id=177
http://amsat-uk.org/satellites/frequencies-of-active-satellites/
http://www.dk3wn.info/p/?page_id=29535
http://www.amsat-dl.org/index.php/satelliten-mainmenu-76/ersicht-aller-mainmenu-102
http://rammb.cira.colostate.edu/dev/hillger/amateur.htm
http://www.klofas.com/comm-table/
http://www.ka9q.net/newsletters.html
http://www.planet4589.org/space/log/satcat.txt
                                                                                                                 bottom top

[Supplement]

FO-29 Mode

Voice/CW Mode JA, Operational
Uplink   	145.900 to 146.000 MHz CW/LSB
Downlink 	435.800 to 435.900 MHz CW/USB

Digital Mode JD, Non-Operational
Uplink     	145.850  145.870  145.910 MHz, FM Manchester Code
Downlink   	435.910 MHz 1200 baud BPSK
Digitalker 	435.910 MHz


Linear inverting heterodyne transponder of FO-29

  Uplink      Downlink
  145.900 --- 435.900
  145.901 --- 435.899
  145.902 --- 435.898
     :           :
  145.950 --- 435.850
     :           :
  145.998 --- 435.802
  145.999 --- 435.801
  146.000 --- 435.800

  i.e. Uplink + Downlink = 581.800


S-band Satellites, Non-Operational

Sat.   No.    Uplink       Downlink     Beacon   Mode         Status
UO-11  14781     .         145.825     2401.500  1200bps PSK  Carrier
AO-16  20439  145.900-960  437.025/051 2401.143  1200bps JAS  Carrier
AO-40  26609  V,U,L,S,C    V,U,L,S,X   2401.323   400bps PSK  S-beacon


AO-40 Frequencies, Non-Operational

Uplink            Digital                  Analog Passband
 15m               none                 21.210 -    21.250 MHz
 12m               none                 24.920 -    24.960 MHz
  2m        145.800 -   145.840 MHz    145.840 -   145.990 MHz
 70cm       435.300 -   435.550 MHz    435.550 -   435.800 MHz
 23cm(1)   1269.000 -  1269.250 MHz   1269.250 -  1269.500 MHz
 23cm(2)   1268.075 -  1268.325 MHz   1268.325 -  1268.575 MHz
 13cm(1)   2400.100 -  2400.350 MHz   2400.350 -  2400.600 MHz
 13cm(2)   2446.200 -  2446.450 MHz   2446.450 -  2446.700 MHz
  6cm      5668.300 -  5668.550 MHz   5668.550 -  5668.800 MHz


Downlink          Digital                  Analog Passband
  2m        145.955 -   145.990 MHz    145.805 -   145.955 MHz
 70cm       435.900 -   436.200 MHz    435.475 -   435.725 MHz
 13cm(1)   2400.650 -  2400.950 MHz   2400.225 -  2400.475 MHz
 13cm(2)   2401.650 -  2401.950 MHz   2401.225 -  2401.475 MHz
  3cm     10451.450 - 10451.750 MHz  10451.025 - 10451.275 MHz
1.5cm     24048.450 - 24048.750 MHz  24048.025 - 24048.275 MHz


Telemetry Beacons (IHU)
     General Beacon(GB)  Middle Beacon(MB)  Engineering Beacon(EB)
  2m          none            145.898 MHz         none
 70cm       435.438 MHz       435.588 MHz       435.838 MHz
 13cm(1)   2400.188 MHz      2400.338 MHz      2400.588 MHz
 13cm(2)   2401.173 MHz      2401.323 MHz      2401.573 MHz
  3cm     10450.975 MHz     10451.125 MHz     10451.375 MHz
1.5cm     24047.885 MHz     24048.035 MHz     24048.285 MHz


                      U         S1         S2          X
RUDAK A    9k6 0    436.006   2400.768   2401.747   10451.561
           9k6 1    435.982   2400.740   2401.720   10451.536

RUDAK B    9k6 0    436.122   2400.887   2401.867
           9k6 1    436.109   2400.870   2401.847

RUD A mod 0 = 2400.791
RUD A mod 1 = 2400.765
RUD B mod 0 = 2400.910
RUD B mod 1 = 2400.891
(measured with an accuracy of +-5 KHz)


AO-40 List (C)JAMSAT

Char.      Freq.    Rem.
     T     21MHz    Uplink
     H     24MHz    Uplink
     V    145MHz    Uplink, Downlink
     U    435MHz    Uplink, Downlink
     L    1.2GHz    2-Uplink, L1 & L2
     S    2.4GHz    2-Uplink, 2-Downlink, S1 & S2
     C    5.6GHz    Uplink
     X     10GHz    Downlink
     K     24GHz    Downlink


Trans. list :
                               UPLINK
   +-----------------------------------------------------------+
   |          T          H          V          U               |
   |  V    167.130    170.840       -       581.575            |
 D |                                                           |
 O |  U    456.830    460.540    581.500       -               |
 W |                                                           |
 N | S1   2421.580   2425.290   2546.250   2836.025            |
 L |                                                           |
 I | S2   2422.580   2426.290   2547.250   2837.025            |
 N |                                                           |
 K |  X  10472.380  10476.090  10597.050  10886.825            |
   |                                                           |
   |  K  24069.380  24073.090  24194.050  24483.825            |
   |_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _|
   |                                                           |
   |          L1         L2         S1         S2         C    |
   |  V   1415.275   1414.350   2546.375   2592.475   5814.575 |
 D |                                                           |
 O |  U   1704.975   1704.050   2836.075   2882.175   6104.275 |
 W |                                                           |
 N | S1   3669.725   3668.800       -          -      8069.025 |
 L |                                                           |
 I | S2   3670.725   3669.800       -          -      8070.025 |
 N |                                                           |
 K |  X  11720.525  11719.600  12851.625  12897.725  16119.825 |
   |                                                           |
   |  K  25317.525  25316.600  26448.625  26494.725  29716.825 |
   +-----------------------------------------------------------+


The above list is quoting from JAMSAT Home Page.

Example : Trans.= (U-Up) + (S2-Down) = 2837.025

We made trial of AO-40 "(U-Up) + (S2-Down)" at the
beginning of May 2001, then we observed as follows.

Approximation after the our observation :

          Trans.= (U-Up) + (S2-Down) = 2836.990

          Up(LSB)     Down(USB)
          435.755 --> 2401.235
          435.690 --> 2401.300
          435.560 --> 2401.430


JF6BCC, Imaishi wrote on AO-40

                  (A)                     (B)
          |------ 95KH ------|    |------ 150KHz -----|
U -Up      435.780 -  435.685       435.645 -  435.495
L1-Up     1269.496 - 1269.400      1269.360 - 1269.211
                   :                        :             (EB)
S1-Dw     2400.245 - 2400.340      2400.380 - 2400.530  2400.600
S2-Dw     2401.210 - 2401.305      2401.345 - 2401.495
                            2401.323
                              (MB)
                             |----|
                      40KHz S2-MB Gird Band


AO-51 Mode (C)AMSAT, Non-Operational

FM Repeater, V/U
Uplink  : 145.920 mhz FM, 67 hz PL Tone
Downlink: 435.300 mhz FM

FM Repeater, V/U, High Power Mode
Uplink  : 145.920 mhz FM, 67 hz PL Tone
Downlink: 435.300 mhz FM

FM Repeater, L/U
Uplink  : 1268.700 mhz FM, 67 hz PL Tone
Downlink: 435.300 mhz FM

FM Repeater, V/S
Uplink  : 145.920 mhz FM, No PL Tone
Downlink: 2401.200 mhz FM

FM Repeater, L/S
Uplink  : 1268.700 mhz FM, No PL Tone
Downlink: 2401.200 mhz FM

FM Repeater, V(ssb)/U (Experimental)
Uplink  : 145.880 mhz USB
Downlink: 435.300 mhz FM

PSK31, 10 meters/U (Experimental)
Uplink  : 28.140 mhz USB, PSK31 Mode Only
Downlink: 435.300 mhz FM

PSK31, V(ssb)/U (Experimental)
Uplink  : 145.860 mhz USB, PSK31 Mode Only
Downlink: 435.300 mhz FM

9k6 Digital, V/U, PBP BBS (Pacsat Broadcast Protocol BBS)
Uplink  : 145.860 mhz FM, 9k6 PBP Digital
Downlink: 435.150 mhz FM, 9k6 PBP Digital

9k6 Digital, V/U, High Power, PBP BBS (Pacsat Broadcast Protocol BBS)
Uplink  : 145.860 mhz FM, 9k6 PBP Digital
Downlink: 435.150 mhz FM, 9k6 PBP Digital

9k6 Digital, L/U, PBP BBS (Pacsat Broadcast Protocol BBS)
Uplink  : 1268.700 mhz FM, 9k6 PBP Digital
Downlink: 435.150 mhz FM, 9k6 PBP Digital

38k4 Digital Downlink, V/U, PBP BBS (Pacsat Broadcast Protocol BBS)
Uplink  : 145.860 mhz FM, 9k6 PBP Digital
Downlink: 435.150 mhz FM, 38k4 PBP Digital

38k4 Digital Downlink, V/S, PBP BBS (Pacsat Broadcast Protocol BBS)
Uplink  : 145.860 mhz FM, 9k6 PBP Digital
Downlink: 2401.200 mhz FM, 38k4 PBP Digital

38k4 Digital Downlink, L/S, PBP BBS (Pacsat Broadcast Protocol BBS)
Uplink  : 1268.700 mhz FM, 9k6 PBP Digital
Downlink: 2401.200 mhz FM, 38k4 PBP Digital


Back to Top
Back to Home Page
